Delta UFC 500

DC 500 kW max- Ultra Fast Charger

Output: 500 kW

Protection: IP55/ IK10

Connectivity: Ethernet, Cellular

• Ultra-rapid 500 kW charging power – designed for heavy-duty vehicles and long-haul fleets

• Supports trucks, buses, and high-capacity EVs

• Kahramaa-approved & CE-certified – compliant with Qatar’s infrastructure regulations

• Dual DC outputs with scalable architecture for future upgrades

• Robust, weather-resistant design for highway and hub installations

• Reduces charging downtime significantly for commercial transport

Ideal for:

Charging Hub

Highways

2 x CCS/ CHAdeMO

Delta UFC 500 kW EV Charger – Next-Generation High-Power Charging for Highways & Heavy-Duty EVs in Qatar. The Delta UFC 500 kW is an ultra-rapid charging solution built for highways, charging hubs, and heavy-duty applications including trucks and buses. CE-certified, Kahramaa-approved, and manufactured in Europe, it provides the highest power delivery in the Delta range for quick top-ups and long-haul fleet efficiency.

Standards & Certifications:

IEC 61851-21-2:2018, EN 61851-1:2019, EN 61851-23:2018, EN 61439-1: 2020, EN 61439-7: 2018, EN 62311:2019, EN 62479:2010, EN 17186:2019, IEC 62196-1:2014, IEC 62196-2:2016 , IEC 62196-3:2020

OCCP 1.6, HW ready for 2.0

Smart controls & Features

20-80%
4 min*

For 100 km
2 min*

* Disclaimer: All values are for reference only and may vary depending on vehicle charging capability, ambient conditions, charger configuration, battery state, and site power availability. Actual charging times and range gained may differ in real-world conditions.
Reference Vehicle: Tesla Model 3 Standard Range | Battery: ≈ 60.9 kWh usable | Energy Consumption: 15 kWh / 100 km
